Appendix C.2. System Trouble Messages
The following table lists the system troubles theoretically recognized by this driver – only a selection have been
tested.
System Trouble
Address
System Trouble
Address
GROUND FAULT LOOP 1
1
STYLE 4 SHORT A L6
255
GROUND FAULT LOOP 2
2
STYLE 4 SHORT B L6
256
GROUND FAULT LOOP 3
3
STYLE 4 SHORT A L7
257
GROUND FAULT LOOP 4
4
STYLE 4 SHORT B L7
258
GROUND FAULT LOOP 5
5
STYLE 4 SHORT A L8
259
GROUND FAULT LOOP 6
6
STYLE 4 SHORT B L8
260
GROUND FAULT LOOP 7
7
STYLE 4 SHORT A L9
261
GROUND FAULT LOOP 8
8
STYLE 4 SHORT B L9
262
GROUND FAULT LOOP 9
9
STYLE 4 SHORT A L10
263
GROUND FAULT LOOP 10
10
STYLE 4 SHORT B L10
264
GROUND FAULT PORT A
11
GENERAL PS FAULT
265
GROUND FAULT PORT B
12
INSTALLATION ERROR OR CPU/AVPS-24 FAULT
266
GROUND FAULT
13
INSTALLATION ERROR OR CPU/AVPS-24 FAULT
267
STYLE 6 NEG LOOP 1
14
INSTALLATION ERROR OR CPU/AVPS-24 FAULT
268
STYLE 6 NEG LOOP 2
15
EARTH FAULT DETECTED IN WIRING OR SYSTE
269
STYLE 6 NEG LOOP 3
16
EARTH FAULT DETECTED IN WIRING OR SYSTE
270
STYLE 6 NEG LOOP 4
17
EARTH FAULT DETECTED IN WIRING OR SYSTE
271
STYLE 6 NEG LOOP 5
18
COMM FAULT LOOP INTERFACE BOARD 1
272
STYLE 6 NEG LOOP 6
19
COMM FAULT LOOP INTERFACE BOARD 2
273
STYLE 6 NEG LOOP 7
20
COMM FAULT LOOP INTERFACE BOARD 3
274
STYLE 6 NEG LOOP 8
21
COMM FAULT LOOP INTERFACE BOARD 4
275
STYLE 6 NEG LOOP 9
22
COMM FAULT LOOP INTERFACE BOARD 5
276
STYLE 6 NEG LOOP 10
23
COMM FAULT LOOP INTERFACE BOARD 6
277
STYLE 6 POS LOOP 1
24
COMM FAULT LOOP INTERFACE BOARD 7
278
STYLE 6 POS LOOP 2
25
COMM FAULT LOOP INTERFACE BOARD 8
279
STYLE 6 POS LOOP 3
26
COMM FAULT LOOP INTERFACE BOARD 9
280
STYLE 6 POS LOOP 4
27
COMM FAULT LOOP INTERFACE BOARD 10
281
STYLE 6 POS LOOP 5
28
CATASTROPHIC ISIB COMMUNICATIONS FAULT 282
STYLE 6 POS LOOP 6
29
MEMORY PATTERN FAULT. SERVICE REQUIRED
283
STYLE 6 POS LOOP 7
30
CATASTROPHIC CPU BOARD COMM FAULT
284
STYLE 6 POS LOOP 8
31
UPLOAD/DOWNLOAD COMMUNICATIONS FAULT 285
STYLE 6 POS LOOP 9
32
STYLE \6\" WIRING OR LOOP #1 ABNORMAL"
286
STYLE 6 POS LOOP 10
33
STYLE \4\" WIRING OR LOOP #1 ABNORMAL"
287
STYLE 6 SHORT L1
34
STYLE \6\" WIRING OR LOOP #2 ABNORMAL"
288
STYLE 6 SHORT L2
35
STYLE \4\" WIRING OR LOOP #2 ABNORMAL"
289
STYLE 6 SHORT L3
36
STYLE \6\" WIRING OR LOOP #3 ABNORMAL"
290
STYLE 6 SHORT L4
37
STYLE \4\" WIRING OR LOOP #3 ABNORMAL"
291
STYLE 6 SHORT L5
38
STYLE \6\" WIRING OR LOOP #4 ABNORMAL"
292
STYLE 6 SHORT L6
39
STYLE \4\" WIRING OR LOOP #4 ABNORMAL"
293
STYLE 6 SHORT L7
40
STYLE \6\" WIRING OR LOOP #5 ABNORMAL"
294
STYLE 6 SHORT L8
41
STYLE \4\" WIRING OR LOOP #5 ABNORMAL"
295
STYLE 6 SHORT L9
42
STYLE \6\" WIRING OR LOOP #6 ABNORMAL"
296
STYLE 6 SHORT L10
43
STYLE \4\" WIRING OR LOOP #6 ABNORMAL"
297
STYLE 6 RING 1
44
STYLE \6\" WIRING OR LOOP #7 ABNORMAL"
298
STYLE 6 ON LOOP 1
45
STYLE \4\" WIRING OR LOOP #7 ABNORMAL"
299
STYLE 6 ON LOOP 2
46
STYLE \6\" WIRING OR LOOP #8 ABNORMAL"
300
STYLE 6 ON LOOP 3
47
STYLE \4\" WIRING OR LOOP #8 ABNORMAL"
301
STYLE 6
48
STYLE \6\" WIRING OR LOOP #9 ABNORMAL"
302
ANNUN 1 TROUBLE
49
STYLE \4\" WIRING OR LOOP #9 ABNORMAL"
303
ANNUN 2 TROUBLE
50
STYLE \6\" WIRING OR LOOP #10 ABNORMAL"
304
ANNUN 3 TROUBLE
51
STYLE \4\" WIRING OR LOOP #10 ABNORMAL"
305
ANNUN 4 TROUBLE
52
UNPROGRAMMED DEVICE ON LOOP 1
306
ANNUN 5 TROUBLE
53
UNPROGRAMMED DEVICE ON LOOP 2
307
