5.4 Client Side Map Descriptor Parameters
5.4.1 FieldServer Related Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where data is to be
stored in the FieldServer One of the Data Array names from
Section 4
Data_Array_Offset Starting location in Data Array
0 to (Data_Array_Length-1) as specified
in Section 4.
Function Function of Map Descriptor Passive
5.4.2 Driver Related Map Descriptor Parameters
Column Title Function Legal Values
Node_Name Name of Node to fetch data from
One of the Node names
specified in Section 5.3
Data_Type Specify memory area type
Detector
Module
Detector_Trouble
Module_Trouble
Panel
Panel_Trouble
Bell_Trouble
Node_Trouble
Address Starting address of block
As per Data_type
Detector
Module
1-1749
Detector_Trouble
Module_Trouble
1-159 for point troubles
Panel
1-1056 for Panel circuits
Panel_Trouble
1-96 for Panel troubles
Bell_Trouble
1-4 for Bell circuits
Node_Trouble
1-509 for Node troubles
Length Length of Map Descriptor Same as address value
Loop*
Specify Loop number. To capture system level events
specify it as 0 or omit this parameter
-, 0-10, 0
Clear_on_Reset*
Specify whether driver should clear Node(s) memory area
upon receipt of “SYSTEM RESET” message from Panel.
No, Yes
Clear_on_Normal*
Specify whether driver should clear Node(s) memory area
upon receipt of “SYSTEM NORMAL” message from Panel.
Yes ,No
