Data Sheet CONNECT2AIR WLAN AP-500RP Issue October 2002
Standard features
§
Conform to IEEE 802.11 and IEEE 802.11b
§ 64 / 128-bit key RC4 encryption
§ MAC Address Control
§ Web-based management
§ Powerful performance for the most demanding
network applications such as Radio Streaming
§ Enhanced roaming across disparate locations and
infrastructures
§ Integrated DHCP Server
§ Supported ISP connection types: PPPoE, PPTP,
Dial-up via Analog/ISDN modem, fix or dynamic IP
Interfaces
§
One RJ-45 port for 10Mbit/s Ethernet WAN
connection
§ Auto-sensing 2-port switch for 10/100Mbit/s
Ethernet LAN connection
§ One serial port for PSTN/ISDN dial-up connection
and console configuration
§ One DB-25 parallel port for printer server
§ High speed wireless LAN (IEEE 802.11b DSSS)
Environmental specifications
Temperature Humidity
Operating 0 ° C to 50 ° C 95% (non condensing)
Storage -10 ° C to 60 ° C 95% (non condensing)
Barometric pressure 740 hPa to 1050 hPa
Hardware specifications
Processor
RDC 8822
Memory 512Kbit DRAM
512Kbit Flash
LAN 2 x RJ-45 LAN / 10/100 Mbit/s
auto-sensing
WAN 1 x RJ-45 WAN / 10 Mbps WAN
Printer port 1 x IEEE1284 DB-25 (parallel)
COM port 1 x DB-9 RS-232C (serial)
Radio characteristics
Frequency Range
2412 MHz to 2462 MHz (ISM)
Channel Frequencies 11 freely selectable channels
Antenna System Diversity antenna
Bit Rate 11 Mbit/s, 5.5 Mbit/s, 2 Mbit/s,
1 Mbit/s (Automatic Rate
Selection)
Output Power 16 dBm (max.)
Typical Range * 11 Mbit/s 1 Mbit/s
open environment 100 m 300 m
closed environment 35 m 100 m
Receiver sensitivity PER < 8% -81 dBm -92 dBm
Typical throughput (excluding
headers, etc) using TCP/IP 5 Mbit/s 0.8 Mbit/s
* Above listed throughput and range values are typical
characteristics and depend on positioning of the
Access Point, Clients and environmental influences
and cannot be guaranteed.
Additional features
§
Seamless roaming within the 802.11b WLAN
infrastructure
§ Provide 10Base-T WAN interface to connect with
DSL or Cable modem for broadband Internet access
§ Asynchronous port for backup routes when the
broadband modem fails or is disconnected
§ Built-in NAT function: allows multiple PCs and
devices to share one Internet connection
§ VPN support: PPTP / IPSec pass-through
§ Built-in firewall to protect your Intranet
§ Access limitation: allow or deny every single
wireless device to access the WLAN or LAN
§ Browser-based interface for configuration and
management: OS independent, easy-to-use for
quick installation and management of the device
§ Easy to upgrade: using Web, Windows application,
or FTP to upgrade new version of firmware
§ Built-in printer server: dedicating a personal
computer as print server is not needed
§ Roaming: AP can be linked via LAN
(Distribution system)
Configuration and management
Web-based Utilities
TFTP support
HTTP server for web-based management
Multilanguage support: German, English, French, Italian
and Spanish
LED displays
Power
Power Indication
M1 System Status AP-500RP
WAN WAN port activity
WLAN Wireless activity
Link/Act. (1, 2) Link status of corresponding LAN port
10/100 (1, 2) Data Rate of corresponding LAN port
System requirements
PC with 802.11b WLAN Card or network card
Includes
AP-500RP AccessPoint
Power cord
Quick Installation Guide
External Power supply, Input 100/240 V AC, 50/60 Hz
CD with software and documentation
Cat. 5 patch cord
Physical specifications
Dimensions:
220 x 142.5 x 38 mm
Weight: 510 g
Supported Operating Systems
AccessPoint configuration: Win 95, Win 98 (SE),
Win ME, Win NT, Win 2000, Win XP, Linux, Macintosh
Printer Server SW: Win 95, Win 98 (SE), Win ME,
Win NT, Win 2000, Win XP
Warranty
2 years
Order code
S26391-F2515-L500
Published by
Fujitsu Siemens Computers
http://www.fujitsu-siemens.ch
All rights, including rights created by patent grant or registration of a utility
model or design, are reserved. Delivery subject to availability; right of
technical modifications reserved.
All hardware and software names used are trade names or trademarks of
their respective manufacturers.
Copyright
Ó Fujitsu Siemens Computers, 11/2002
