23
F-SERIES
(March, 2005)
STATEMENTS OF CONFORMITY
HOLES (12 PLACES)
OF BRACKET
3/16 INCH
BLIND RIVET *
(12 REQ’ D)
87.0
[3.42]
78.0
[3.07] 48.0
[1.89]
48.0
[1.89]
78.0
[3.07]
48.0
48.0
[1.89]
105.7
[4.16]
67.5
[2.66]
48.0
[1.89]
81.0
[3.19]
616.0
[2.42]
75
POINT Z
SECTION U
U
U
VIEW P
48.0
48.0
[1.89]
81.0
[3.19]
CL
REFER TO CALIFORNIA
FUEL VAPOR RECOVERY
REQUIREMENT.
P
C
A
SCREWS (3 REQ’D)
TORQUE 1.7-2.8
NEWTON METERS
[15-25 IN. LB.]
[1.89]
[1.89]
SUB
TO BACK
OF CAB
CL OF FILL PIPE ASY.
AND BRACKET
FRONT OF
VEHICLE
PROTECTIVE SLEEVES ARE
REQUIRED ON BOTH FILL AND
VENT HOSE WHERE PASSIN G
OVER FRAME.
SCREWS (3 REQ’D)
TORQUE 1.7-2.8
NEWTON METERS
[15-25 IN. LB.]
RECIRCULATION
HOSE
OUTBOARD SURFAC E
OF FRAME RAIL
FILL HOSE
90º FITTING - CONNECT TO
QUICK CONNECTION ON VAPOR LINE
#4 CROSSMEMBER
TOP OF FRAME RAIL
TOP OF FRAME RAIL
C
AT L OF FILL PIPE
INSTALL GROUND WIRE TO
SOUND METAL ON THE FRAME.
THIS HOSE IS PREFORMED; INSTALL SHORT EN D
TO THE METAL NECK AND CAP ASSEMBLY;
TRIM THE LONG END AS REQUIRED.
STEEL ELBOW
DO NOT TRIM
RECIRCULATION
STEEL TUBE
RECIRCULATION
HOSE CLAMP
STEEL ELBOW
DO NOT TRIM
CAP
1/4 TURN - GASOLINE - LEV II
SCREW IN - DIESEL
D
NOTES:
TORQUE ALL WORM GEAR DRIVEN HOSE CLAMPS
TO 2.8 - 3.9 NEWTON METERS [25-35 IN. LB.]
[ ] DIMENSIONS ARE INCHES
* NOT SUPPLIED BY FORD MOTOR COMPANY
Remove and discard the Ford installed fuel fill system components
(provided for shipping purposes only) except save and reuse the
metal neck and cap assembly.
Use the new hoses, pipes, scuff guards, tie wraps, and clamps
provided in the dunnage kit.
The completed fuel fill system must provide a 4 degree minimum,
continuous, downward slope to the fuel tank. Additional support may
be required to prevent hose sagging which could cause spray or
spitback during normal fueling operations.
Do not extend the fuel fill system outboard of the second unit body.
(CA) BACK OF CAB TO CENTERLINE OF REAR AXLE
56 INCH CA
WHEELBASE
Regular Cab
Super Cab
Crew Cab
3480mm [137.0]
4013mm [158.0]
4380mm [172.4]
MIN 620mm [24.4]
A
MAX 923mm [36.7]
MIN 540mm [21.25]
C
MAX 743mm [29.25]
MIN 267mm [10.5]
D
MAX 343mm [13.5]
FIGURE B – SUPER DUTY F-SERIES WIDE FRAME PICKUP BOX DELETE FUEL FILLER PIPE INSTALLATION
