FS-8700-105_National_Time_and_Signal_FACP Manual Page 18 of 25
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]
Relative
Offset
4
Description
6 Increments each time a port 'Alive' message is received
7 Increments each time a message is received and is sent to the parsing routine
8
Increments by message length each time a message is received and is sent to the
parsing routine
9 Increments each time a message is received and is sent to the parsing routine
10 Increments each time a message is received and is sent to the store routine
11
Increments each time a message is received and is sent to the store routine and
results in a store
12 Increments each time a message is received and is sent to the reset routine
13
Increments each time a message is received and is sent to the reset routine and
at least one DA was reset
14 Panel Number: Most recent message (after parse, prior to store)
15 Board Number: Most recent message (after parse, prior to store)
16 Loop Number: Most recent message (after parse, prior to store)
17
Port Type: Most recent message (after parse, prior to store). ASCII value
shown. ASCII value shown.
28 Port Number: Most recent message (after parse, prior to store)
19
Sub Port Type: Most recent message (after parse, prior to store). ASCII value
shown.
20 Sub Port: Most recent message (after parse, prior to store)
21 Trouble String Index: Most recent message (after parse, prior to store)
22
Trouble Level: Most recent message (after parse, prior to store). Ascii value
shown.
Data_Arrays,
Data_Array_Name, Data_Format, Data_Array_length,
natsfacp-stats, UINT32, 1000,
Appendix B.3. Driver Error Messages
Message Interpretation and Corrective Action
NATS:#01a FYI Validation
ignored for simulation.
MD=%s
This message is normally only printed when the driver is
being tested for QA purposes. If it is printed during
normal operation, take a log and call Technical support.
There are a number of variants of this message. Be sure to
quote the correct one when reporting the error.
NATS:#02a Err. Bad Port-
Type=0x%x. Expected
I/O/F/P.
A Map Descriptor is being validated and has been rejected
because the ‘Port-Type’ has not been correctly specified
∗
