09
specifications
English
Profile 918 Profile 908 Profile CC 908
Type 2 1/2-way bass-reflex floor standing
loudspeaker
2-way bass-reflex bookshelf loudspeaker 3-way bass-reflex shielded center channel
Drivers 1’’ Al/Mg inverted dome tweeter
6-1/2’’ "W" cone mid-bass,1-1/4’’ voice coil
6-1/2’’ "W" cone woofer, 1-1/2’’ voice coil
1’’ Al/Mg inverted dome tweeter
6-1/2’’ "W" cone mid-bass, 1-1/4’’ voice coil
1’’ Al/Mg inverted dome tweeter
3’’ "W" cone midrange, 1’’ voice coil
Two 6-1/2’’ "W" woofers, 1’’ voice coil
Frequency response (-3dB) 40 to 30.5kHz 50 to 30.5kHz 65 to 30.5kHz
Sensitivity (2.83V/1m) 90dB 89dB 91dB
Nominal impedance 8Ω 8Ω 8Ω
Minimum impedance 3.2Ω 3.7Ω 4.2Ω
Max power handling 200 Watts 90 Watts 150 Watts
Crossover frequency 180Hz / 2600Hz 2600Hz 500Hz / 2600Hz
Dimensions (HxWxD) 39x9x13.8’’ (990x230x350mm) 15.3x9x10.8’’ (390x230x275mm) 8.1x24.9x12.8’’ (205x632x324mm)
Net weight 43lbs (19.5kg) 18.7lbs (8.5kg) 31.9lbs (14.5kg)
