4.3. Client Side Node Descriptors
Section
Title
Nodes
Column
Title
Function Legal Values
Node_Name Provide name for node
Up to 32
alphanumeric
characters
Node_ID
These correspond to the ‘devices’ configured in the
DTPConfig. Thus the Node_ID is not the address of the final
CCN device.
The DataPort DTPConfig table maps a device number
(1...15) to a bus number (0-239). Use the Node_ID to tell the
driver which device to use.
1-15
Protocol Specify protocol used CarrierDP
Port Specify which port the device is connected to the FieldServer P1-P8, R1-R2
3
Example
// Client Side Nodes
Nodes
Node_Name, Node_ID, Protocol , Port
FAN1 , 1 , CarrierDP, P8
3
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports available on specific hardware.
