Maintenance
Maintenance
4
4-3
46 R22,
23
302041
Resistor, Film, 200k, .25W,
5%
2
47
R20, 26,30,
32,33,38,
341041
Resistor, Film, 100k, .25W,
5%
6
49
R27, 29,31, 34,40 341032
Resistor, Film, 10k, .25W,
5%
5
50 R13-18,
28
185-1448
Resistor, Film, 200, .25W,
5%
7
51
R24
185-2496 Resistor, Film, 2k, .25W, 5%
1
52 R25,
41
342031
Resistor, Film, 20k, .25W,
5%
2
53 R21,
39
303351
Resistor, Film, 3.3m, .25W,
5%
2
54 R3
391052
Trim Pot, 1M, .5w, 20%,
Open
1
55
R36
300501 Resistor, Film, 5.1, .25W, 5%
1
57
T1
700003
Transformer, H.V., OSC
1
58
S1
560009
Switch, Rotary, 6-pos,
1
59
44-16
Washer, Flat, .25 ID/.41 OD
1
60
33-139-
16
Socket, 16-Pin IC, PCB MNT
4
61
33-139-
14
Socket, 14-Pin IC, PCB MNT
3
63
0998002
Double-sided Tape, 3/4 x 1
1/16
1RL
