Victoreen 05-437
Operators Manual
4-2
Table 4-2. PC Board Assembly (126021) Parts List
Item No. Ref. No. Part No. Description Qty
6 V1 010054 Tube Shield Assembly 1
7 U1, 4 630001 IC, Quad Nor Gate, 4001 UB 2
8 U7 630002
IC, Quad Nand Gate, 4011
UB
1
9 U5, 6 630006 IC, Quad Latch, 4043B 2
10 U2, 3 630008
IC, 12 Stage Counter,
4040BE
2
12 D1 600005 Diode 1N5243B 1
13 D2, 3,4 600001 Diode 1N4006RL 3
14 D5, 6 600003 Diode1N414B 2
15 Q1, 2 620001 Transistor 2N4124 2
16 Q4-9 620003 Transistor, S.C.R. MCR-103 6
17 Q11, 12 620003 Transistor, MPS-A13 2
18 11,2 680009 REDT-1 Hi-Intensity LED 2
19 13,4 680008 Yellow T-1 LED 2
20 15-7 680007 Green T-1 LED 3
23 A1 710002 12 VDC Audio Alarm 1
24 U8 640001 IC, +6 V Regulator, 78M06 1
25 5-196 Screw, PH, 4-40 x .38 1
26 5-764 Washer, INT, 4, s, CP 1
27 5-850 Nut, Hex, 4-40, 5, CP 1
28 0911403 Screw, BH, 6-32 x .25, 5 1
29 5-766 Washer, INT, 6, 5, CP 1
30 0976002 Binding Post, 6-32 PCB MNT 1
31 110-11 780006
Lamp Holder, T-1 3/4 PCB
MNT
2
32 110-11 680010
Lamp, T-1, 3/414 V @ 1A,
#74
2
33 T1 780013 Microphone Jack 1
34 A1 780014 Power Jack 1
35 C1 212221
Cap, Film, 2200 PF, 250 V,
10%
1
36 C8, 14,16, 17 211031
Cap, Film, .01 μF, 250 V,
10%
4
37 C13, 15,23 211032 Cap, .01 μF, 100 V, 20% 3
38 C5, 7,20 211041 Cap, Film, .1 μF, 160 V, 10% 3
39 C6, 22 232252
Cap, Tant, 2.2 μF, 16 VDC,
20%
2
40 C9, 10,11 201031 Cap, .01 μF, 1000 V, 20% 3
41 C21 214741
Cap, Film, .47 μF, 100 VDC,
10%
1
42 C3, 4 201021 Cap, 1000 PF, 500 V, 20% 1
45 R2, 5-10,37 185-1434
Resistor, Film, 510k, .25W,
5%
8
