Cleaning
5-2 C156-F046-01EN
IMPORTANT
Check the cleaning brush state by opening the shutter of the head cleaner. If the
tip of brush is open, used new head cleaner.
5.2 MO Cartridge Operation
5.2.1 MO cartridge
Figure 5.1 shows the MO cartridge. For operation and cleaning, users should be
familiar with the parts shown in the figure.
• Shutter closed
• Shutter open
Figure 5.1 MO cartridge
5. Hub
4. Disk
3. Write protect tab
1. Cartridge case
2. Shutter
