Frymaster Portable Filters MF90 Series User Manual
Page 29
7-3
7.1 MF-90/65, U and AU Configuration (cont.)
ITEM
PART #
COMPONENT
38
1036
Nut, ½- inch Flare 37°
39
1037
Tubing Sleeve ½- inch 37°
40
1034
Tube, SS, [ ½- inch Diameter x Feet]
41
55-0007
Plate, IN-OFF-OUT (AU Only)
*
1081
Plate, PUMP-OFF-HEAT (with Heater Option)
*
1678
Plate, ON-OFF (U Only)
42
1385
Switch, 3PDT 90 Amp Push ON
*
1083
Switch, Toggle SPDT (U Only, With Heater Option)
*
1541
Switch, Toggle (U Only, No Heater Option)
43
44-0443
Handle, Ball Valve, (3/8- inch)
44
1856
Clamp, Pipe ½- inch (Jiffy H-40)
45
44268
Holster, Hose Assembly
46
1032
Screw, 10-32 x ½- inch Round Slotted Head
47
2081
Clamp, Draw (HR-1)
48
1096
Connector, 3/8- inch x 45°
49
1092
Connector, 3/8- inch x 90°
50
1098
Conduit, 3/8- inch Flex
51
2053
Inlet Flanged Base 120V
52
2059
Power Cord,1613 SJTO
53
2036
Circuit Breaker (7 Amp- 120V Applications)
*
2175
Circuit Breaker (5 Amp- 230V Applications)
54
44282
Motor/Pump Cover Assembly (AU-65)
55
44285
Filter Pan Assembly (U/AU-65 /Clamp)
56
1033
Screw, ¼-28 x ½ Round Phillips Head
57
2009
Nipple, Black Pipe [ ½ NPT x 2-½ -inch]
58
1391
Elbow, ½- inch, 45° Black Pipe
59
1075
Nipple, Black Pipe ½NPT x 3-inch
60
55191
Quick Disconnect Assembly ( ½-inch)
61
1645-1
O-Ring
62
55156
Wire Grid and Channel Assembly (#12)
63
1334-PK
Filter Paper, 11 x 22-5/8 (20 Sheets/Pack)
*
1334
Filter Paper, 11 x 22-5/8 (100 Sheets/Pack)
64
55127
Hold-Down Ring w/Handle Assembly
65
55-0011
Lever, Hold-Down Ring
66
44262
Pan Assembly, w/o clamps
67
1016
Connector, Male 3/8”
68
55228-SC
Handle Assembly
69
55-0121
Nozzle, Threaded (One End)
70
44-0450
Nozzle, Threaded (Both Ends)
71
55-0264
Pipe Screen
72
44286
Pan, Lid Assembly
*
44-0447
Pan Lid Only
73
1039
Handle, Filter Pan Lid (w/Screws)
