7-2
7.1 MF-90/65, U and AU Configuration (cont.)
ITEM PART # COMPONENT
1 44272-1 Frame Assembly
2 44-0409 Caster Channel
3 1004 Bolt, ¼ - 20 x ½- inch Hex
4 1008 Washer, Flat ¼- inch
5 1005 Nut, Nylock ¼-20
6 2376 Caster, 3- inch, w/o Brake
7 2736 Caster, 3- inch w/Brake
8 1832 Washer, Flat, ½- inch
9 1709 Nut, ½-13 Hex
10 44267 Electric Box Assembly (U65 w/o Heater)
* 44267-2 Electric Box Assembly (AU/65 w/Heater)
* 44267-1 Electric Box Assembly (U/65 w/Heater)
11 1025 Screw, #8 x ½ Type B
12 1892-2 Motor, 1/3HP 230/120V/50/60Hz
* 1726-1 Pump, 5 GPM (18 LPM)
13 1059 Nipple, Black Pipe ½ x 1-½- inch
14 1013 Elbow, ½ x 3/8- inch 90° Black Pipe
15 2083 Nipple, 3/8 x 3-½ -inch
16 1989 Elbow, 3/8 x 45°
17 1014 Nipple, Black Pipe, 3/8" x Close
18 55016 Couple Assembly (Snap-Tight)
19 1350 Seal, Viton Quick-Disconnect
20 44287 Nozzle and Hose Assembly, Complete
* 55220 Nozzle and Hose Assembly
21 1687 Elbow, Street, Black Pipe, ½- inch x 90°
22 1061 Union, Black Pipe, ½- inch
23 1765 Tee, Black Pipe, ½ x 3/8 x ½- inch
24 1012 Nipple, Black Pipe [ ½ NPT x 6- inch]
25 1057-SC Check Valve, Swing ½-(Plated)
26 1011 Elbow, Black Pipe, ½-inch x 90°
27 1076 Nipple, Black Pipe ½NPT x 3-½-inch
28 44291 Hose Assembly w/Fitting (L= 11.75- inch)
29 1644 Quick-Disconnect Male ½- inch
30 1798 Nipple, Black Pipe, [3/8NPT x 2- inch]
* 1799 Nipple, Black Pipe [3/8NPT x2-½- inch ]
31 1043 Elbow, 3/8- inch x 90°
32 44-0379 Holder, Power Cord
33 1100A Valve, Ball- 3/8-inch
34 55-0004 Bolt, Hold-down Handle
35 1010 Nipple, Black Pipe, ½- inch x Close
36 2124 Nipple, Black Pipe[3/8 NPT x 7- inch]
37 1985 Flare Fitting 3/8- inch NPT
