2-3
ITEM PART # COMPONENT
1 Motor, Basket Lift
807-0107 120 VAC
807-0108 240 VAC
2 807-0124 Bushing, Plastic
3 807-0240 Microswitch, BA-2RV22-D6
4 809-0047 Nut, ¼-20 Hex Head Cap
5 826-1358 Nut, 6-32 Hex Head (Pkg. of 25)
6 809-0050 Nut, 8-32 Hex Head
7 809-0063 Nut, ¾-inch Jam
8 809-0076 Nut, ¼-20 Expansion
9 809-0082 Ring, Retaining (secures Item 24 in place)
10 809-0097 Screw, 6-32 x 1-inch Slotted Truss Head
11 826-1363 Screw, 8-32 x ½-inch Slotted Truss Head (Pkg. of 25)
12 809-0113 Screw, 8-32 x 1½-inch Slotted Truss Head
13 809-0127 Screw, ¼-20 x ½-inch Slotted Round Head
14 826-1370 Screw, ¼-20 x 1½-inch Slotted Round Head
15 809-0155 Screw, Leveling
16 809-0190 Washer, ¼-inch SS Flat
17 809-0196 Washer, ⅜-inch Flat
18 809-0200 Washer, ¼-inch Flat
19 826-1381 Washer, ½-inch Nylatron (Pkg. of 10)
20 809-0247 Nut, 8-32 Hex Head Keps
21 826-1374 Screw, #10 x ½-inch Hex Head (Pkg. of 25)
22 809-0480 Setscrew, ¼-28 x 5 ⁄
8
-inch (secures Item 25 to motor shaft)
23 809-0508 Bolt, ¼-20 x ¼-inch SS AT Hex Head
24 813-0035 Bushing, .875 Hole
25 810-0052 Bellcrank (Cam)
26 810-0170 Pin, ¼-inch x 5 ⁄
8
-inch Spring Dowel
27 810-0172 Button, Plug
28 810-0192 Rod, Basket Lift
29 810-0194 Roller, Basket Lift
30 810-0220 Spacer, .493-inch x .200-inch Tubular
31 810-0374 Spacer, Basket Lift Roller Tubular
32 812-0138 Insulation, Paper
33 823-2007 Arm Assembly, GSMS/GBC Basket Lift
34 900-7416 Mount, Basket Lift Motor
35 900-7418 Back, Upper Basket Lift Enclosure
36 900-7419 Back, Lower Basket Lift Enclosure
37 900-7421 Support, Basket Lift Center
38 901-1927 Bracket, Left Basket Lift Roller
39 902-1927 Bracket, Right Basket Lift Roller
40 910-4525 Bar, Basket Lift Synchronizing
41 910-7420 Top, Basket Lift Enclosure
42 911-7417 Side, Basket Lift Enclosure
43 912-7417 Side, Basket Lift Enclosure
44 920-6076 Link, Basket Lift
NOTE: Order KIT0004SP to add a complete basket lift assembly to a GC unit.
