button advances the display through the
options. Options are:
a) US gallon units. Display will show
“US GAL”, display - “G/H XX.X”.
b) Imperial gallons units. Display will show
“IMP GAL”, display - “I/H XX.X”.
c) Liters. Display will show
“LITERS”, display – “L/H XX.X”.
Leaving the display in one of the items
above while the “mode-M” button is
pressed and held for more than one second
will save the selected units.
Trip Fuel Consumed
Displays the amount of fuel consumed
since last reset. Can be reset to zero prior
to a trip to show fuel consumed during the
trip. Display will show “TRPXXX.X”.
Pressing the “mode-M” for more than one
second will access the options that are
available for this function.
A short press of the “mode-M” button
advances the display through the options.
Display will show “TRPXXX.X”. Options
are:
a) Clear Trip Fuel Consumed. Display
will show “CLR TRP”. Pressing the mode-
M button for more than one second while
the display shows “CLR TRP” will clear
the trip amount and set the menu back to
the Trip Fuel Consumed function. A quick
press of the “mode-M” button will skip
this feature.
b) Adjust Trip Fuel Consumed, (fuel flow
calibration). Display will show “ADJ TRP”.
Pressing the “mode-M” button for more
than one second will cause the display to
go into the Trip Fuel Consumed adjustment
menu.
The display will show “ADJXXX.X”.
Pressing and holding the “Up” button will
increase the amount and pressing and
holding the “Down” button will decrease
the amount.
Holding the “mode-M” for more than one
second while the display is showing
“ADJXXX.X” will set the amount in the
display “XXX.X” into the Trip Fuel
Consumed and return to the Trip Fuel
Consumed function. The difference between
the original and the new amount of fuel will
be used to change the calibration of the
instant and accumulated fuel data.
This feature allows the fuel flow system to
be calibrated by accurately filling the fuel
tank at the beginning and end of a trip.
When the tank is refilled at the end of the
trip, record the exact amount of fuel placed
in the tank. Using the above procedure,
adjust the amount of fuel shown in the
“ADJ TRP” to match the amount of fuel
recorded. Save the corrected amount as
described above. The Trip Fuel Consumed
in the previous menu can then be cleared
M Mode
Button
M Mode
Button
M Mode
Button
M Mode
Button
Down
Button
Up
Button
Page 6
SystemCheck® Error Codes
CODE DESCRIPTION
Page 9
12 See Dealer - code 12
13 Throttle cable adjustment at idle - code 13
14 Throttle cable adjustment at WOT - code 14
15 EMM problem - See dealer - code 15
16 Crank sensor problem - See dealer - code 16
17 Low injector voltage - code 17
18 High injector voltage - code 18
22 Engine overheat - See owner’s manual - code 22
23 See Dealer – code 23
24 See Dealer - code 24
25 ECU/EMM overheat - code 25
26 Low battery voltage
27 High battery voltage
28 Shift assist problem – See dealer code 28
29 Engine shutdown – ECU temp – See dealer – code 29
31 Engine shutdown - Eng temp – See dealer – code 31
34 Oil system problem - See dealer immediately - code 34
35 Oil pressure loss - See dealer immediately - code 35
37 Water in fuel - See owners manual - code 37
38 No oil feedback – See dealer – code 38
39 Oil prime failure – See dealer – code 39
45 See Dealer - code 45
46 See Dealer - code 46
48 Low air temp - code 48
49 High air temp - code 49
51 #1 Fuel injector problem - See dealer - code 51
52 #2 Fuel injector problem - See dealer - code 52
53 #3 Fuel injector problem - See dealer - code 53
54 #4 Fuel injector problem - See dealer - code 54
55 #5 Fuel injector problem - See dealer - code 55
56 #6 Fuel injector problem - See dealer - code 56
57 Engine Malfunction - Do not restart engine – Seek
assistance to return to port – code 57
81 #1 Ignition coil problem - See dealer - code 81
82 #2 Ignition coil problem - See dealer - code 82
83 #3 Ignition coil problem - See dealer - code 83
84 #4 Ignition coil problem - See dealer - code 84
85 #5 Ignition coil problem - See dealer - code 85
86 #6 Ignition coil problem - See dealer - code 86
Other SystemCheck messages
Low oil level – Add oil to the oil tank
