Assembly – Fisher-Price BARBIE SONGBIRD 76922 User Manual

Page 12

Note: If you have already charged your Power Wheels

6 Volt (4.0 Amp/Hr.) battery for at least 18 hours, you may
want to install it in the battery compartment before assem-
bling the seat to your vehicle. Please refer to the Battery
Installation section beginning on page 14 for instructions.

• Insert the tabs on the front of the seat into the slots in the

vehicle body.

• Press down on the back of the seat to snap the tabs on

the back of the seat into the slots in the vehicle body.

• Using a slotted screwdriver turn the lock fastener a

quarter turn to lock seat into place.

• Once the seat is assembled to the vehicle body, use a

slotted screwdriver to rotate the lock fastener

turn to

the locked position

• To unlock the lock fastener, use a slotted screwdriver

to rotate the lock fastener

turn to the unlocked

position .

IMPORTANT! Remember to keep the lock fastener
locked at all times to prevent children from accessing
the vehicle battery.

Seat

Lock
Fastener

Lock Fastener

LOCKED

UNLOCKED

• Insert three #8 x

" screws through the battery

compartment in the vehicle body and into the footrest.

Footrest

Vehicle Body

Peg

Footrest

• Fit the footrest to the peg on the underside of the

vehicle body .

Assembly
