6
1.3 IF Cable Specifications
Table 1.3a lists the IF cable components, Table 1.3b lists the general specifications of
the IF cable, and Figure 1.3 shows the dimensions of the IF cable.
■ IF cable specifications
For an explanation of connecting the adapter to the main unit, see Section 2.2, “Connection to
Main Unit.”
Table 1.3a IF cable components
Part name Remarks
FCN-237R068-G/E connector
×
2 Fujitsu
FCN-230C068-C/E cover
×
2 Fujitsu
Table 1.3b IF cable general specifications
Item Contents
Rated current DC1A
Temperature
Operating −
10 to
+
60
o
C
Storage −
10 to
+
60
o
C
Weight 140g
