Five Piece Cabinet Bit Set
• All bits have 1/2" shanks and are designed to be used on 3/4" stock.
• Includes attractive wooden storage box.
• Cuts all composition materials, plywoods, hardwoods, and softwoods.
• Use on table-mounted portable routers with 1/2" shank.
Application: Produce your own cabinet doors at a fraction
of the cost of shaper heads
Five Piece Cabinet & Molding Bit Set
• All bits have 1/2" shanks and are designed to be used on 3/4" stock.
• Includes attractive wooden storage box.
• Cuts all composition materials, plywoods, hardwoods, and softwoods.
• Use on shank table-mounted portable router with 1/2" shank.
Application: Create your own cabinet doors and more than 39
molding patterns
# 94-100
# 95-100
229
ROUTER BITS & SETS
Router Bit Sets
Red Item Numbers Indicate 1/2 " Shank See individual bit for scale profile
New
Storage
Box
New
Storage
Box
Video-CD
Included
R
a
is
e
d
P an
el
Doors Ma
de
S
im
p
le
Bit Type Item Overall Cut Small Carbide Minor Large Small Angle Shank Overall
Number Dia. Depth Dia. Height Height Radius Radius Dia. Length
Item Number 94-100
Door Lip Bit 99-001 2" 29/64" – 1-1/4" 11/16" 3/8" – 7° 1/2" 2-3/4"
2 + 2 Raised Panel Bit 99-510 2-3/4" – – 5/8" 7/32" 35/64" 1/8" – 1/2" 2-1/2"
Reversible Glue Joint Bit 99-031 1-1/2" – 1-3/16" 1-1/4" 23/64" – – 30° 1/2" 2-3/4"
Rail & Stile Bit Set 99-260 1-11/16" – 1-5/16" 11/16" 15/64" 7/32" – – 1/2" 3"
# 99-510 # 99-031 # 99-001 # 99-260
# 99-510
# 99-031 # 99-260
# 99-PK1
Bit Type Item Overall Small Carbide Minor Large Small Small Angle Shank Overall
Number Dia. Dia. Height Height Radius Radius1 Radius2 Dia. Length
Item Number 95-100
Reversible Glue Joint Bit 99-031 1-1/2" 1-3/16" 1-1/4" 23/64" – – – 30° 1/2" 2-3/4"
2 + 2 Raised Panel Bit 99-510 2-3/4" – 5/8" 7/32" 35/64" 1/8" – – 1/2" 2-1/2"
Multi-Profile Bit 99-PK1 2-5/32" – 1-59/64" – 25/64" 5/16" 15/64" – 1/2" 4"
Rail & Stile Bit Set 99-260 1-11/16" 1-5/16" 1-1/16" 15/64" 7/32" – – – 1/2" 3"
