232

ROUTER BITS & SETS

Router Bit Sets

Eight Piece Bit Sets for Incra Jig

• Follow the directions in the Incra Jig

manual and use the correct bit

number for the joint you want to create.

• Both sets produce identical profiles.
• Includes attractive wooden storage box.
• Cuts all composition materials, plywoods, hardwoods, and softwoods.
• Use on table-mounted portable routers equipped with Incra Jig

• Can also be used with other joint making jigs or fence systems and CNC

automatice routers.

Application: Create dovetail and box joints by combining
these bits with your table-mounted router equipped with an
Incra Jig

Red Item Numbers Indicate 1/2" Shank

See individual bit for scale profile

#96-100

Bit Type

Item

Overall

Carbide

Angle

Shank

Overall

Number

Dia.

Height

Dia.

Length

Item Number 96-100
Double Flute Straight Bit*

04-106

1/4"

3/4"

–

1/4"

2-1/4"

Double Flute Straight Bit

04-124

3/8"

–

1/4"

2-1/2"

Dovetail Bit

22-100

1/4"

5/16"

7-1/2°

1/4"

Dovetail Bit

22-101

5/16"

3/8"

9°

1/4"

1-7/8"

Dovetail Bit

22-102

3/8"

9°

1/4"

1-7/8"

Dovetail Bit

22-104

1/2"

14°

1/4"

1-7/8"

Dovetail Bit

22-105

3/8"

7/8"

7°

1/4"

2-1/8"

Dovetail Bit

22-106

3/4"

7/8"

7°

1/4"

2-1/8"

Item Number 96-102

Double Flute Straight Bit

12-100

1/4"

3/4"

–

1/2"

2-3/8"

Double Flute Straight Bit

12-108

3/8"

–

1/2"

2-5/8"

Dovetail Bit

22-107

1/4"

5/16"

7-1/2°

1/2"

2-5/8"

Dovetail Bit

22-108

5/16"

3/8"

9°

1/2"

2-1/8"

Dovetail Bit

22-110

3/8"

9°

1/2"

2-1/4"

Dovetail Bit

22-112

1/2"

14°

1/2"

2-1/4"

Dovetail Bit

22-113

5/8"

7/8"

7°

1/2"

2-5/8"

Dovetail Bit

22-114

3/4"

7/8"

7°

1/2"

2-5/8"

* Solid Carbide
Incra Jig

is a registered Trademark of Taylor Design Group

Double Flute

Straight Bit Profile

Dovetail Bit Profile

Three Piece Cove Bit Sets

• Includes 1/4", 3/8" and 1/2" radius cove bits and an attractive

wooden storage box.

• Cuts all composition materials, plywoods, hardwoods, and softwoods.
• Use on hand-held and table-mounted portable routers.

Application: Produces classical decorative edge on furniture
and moldings

# 89-500

Bit Type

Item

Overall Bearing Carbide

Large

Shank Overall

Number

Dia.

Height

Radius

Dia.

Length

Item Number 89-500
Cove Bit

30-102

7/8"

3/8"

1/2"

1/4"

2-3/16"

Cove Bit

30-104

1-1/4"

1/2"

3/8"

1/4"

2-3/16"

Cove Bit

30-106

1-1/2"

1/2"

5/8"

1/2"

1/4"

2-3/16"

Item Number 89-550

Cove Bit

30-110

1/2"

1/4"

1/2"

2-1/2"

Cove Bit

30-112

1-1/4"

1/2"

3/8"

1/2"

2-1/2"

Cove Bit

30-114

1-1/2"

1/2"

5/8"

1/2"

2-1/2"

Cove Bit Profile

New

Shadow

Box
