Speed Control
The ATF 55E has electronic speed control so the speed of the
blade remains constant regardless how much the motor is
loaded. The speed of the motor should be set according to
the type of material being cut.
Figure 18
18-a Speed Control Knob
18-b Pointer
18-c Power Indicator
Adjustment Settings
Turn the speed control knob (18-a) so the speed indicator
lines up with the pointer (18-b).
Material Speed
Soft wood products and veneer plywoods
6
Hardwood products prone to burning
when cut (i.e. cherry and maple)
3-6
Plastic laminate countertops 6
Hard plastics 3-5
Soft plastics 1-4
Masonry and cementitious hardboard 1-3
Aluminum 4-6
Power Switch
Figure 19
19-a Plunge Release Lever
19-b Power Switch (trigger)
To prevent unexpected start-ups, the power switch has an
integral safety interlock. Before the saw can be started, the
plunge release must be engaged.
1. Press up on the plunge release lever.
2. Pull back on the power trigger.
Bevel Setting
Bevel cuts are made when the blade is tilted with respect to
the sole plate.
Figure 20
20-a Front Locking Knob
20-b Rear Locking Knob
20-c Bevel Setting Gauge
Setting the Bevel Angle
1. Loosen the front (20-a) and rear (20-b) locking knobs.
2. Tilt the saw to the desired angle as indicated on the
bevel setting gauge (20-c).
3. Re-tighten the two locking knobs.
Instruction Manual 13
