ULTRA-ZONE HUMIDIFIER

Z100 ASSEMBLY

INSTALLATION INSTRUCTIONS & OWNER'S MANUAL
Z100 REPLACEMENT INSTRUCTIONS
SUPPLEMENT TO THE ULTRA-ZONE ELECTRONIC STEAM POWER HUMIDIFIERS
MODEL # S2000 AND S2020

AN 131

The ULTRA-ZONE steam humidifier now comes equipped with a factory installed Z100, which acts as a
sacrificial metal. Put simply, the chemicals in the water will attack and cling to the

. The chemicals

will not attack the other components inside the humidifier as long as the

Is active.

This results in a dramatic decrease in chemical and scale build up on the stainless steel components
inside the tank. In particular, it means less scale build up on the heating element which is subject to
damage from excessive scaling and over heating. This also means that efficiency stays high and
preventive maintenance is

and

The

is positioned on the baffle plate inside the tank and is easily removed and replaced.

Remember that the

’s job is to become the target of chemical attack, so it will be heavily covered

with scale and should be replaced annually for best results.

To remove the

you must have already unplugged and shutdown your steam humidifier and

allowed it to cool. The water tank has been drained, the water supply, drain lines and electrical wiring
have been disconnected and the unit has been removed from the duct.

Using a phillips screwdriver, remove the two screws that hold the baffle plate to the tank. Lift the baffle
slightly back to clear the water probe and then straight up and out of the tank. You can then see the
round

, or rather what is left of it after a single season. Notice the heavy scale build up on the

that would have been on your element, if the

was not there. Use a rag or pliers to grasp the edges

of the

and simply unscrew it from the baffle plate. Rinse off or wipe away any residual scale from

the baffle plate and install the new

. Leave a slight gap between the bottom of the

and the

baffle plate. Now re-insert the baffle plate into the tank and secure with the two screws that were
removed previously. It’s that simple.

The

can also benefit the older model steam humidifiers. Simply lay the

down into the baffle

plate in the same location as the factory installed model. DO NOT lay the

down into the main

tank. It may come in contact with the heating element and damage it. The dimensions of the baffle
plate prevent the

from falling down into the tank.

The Z100 is just the latest innovation in the ULTRA-ZONE Steam Humidifier line as we continue in our
pursuit of Excellence Without Compromise.

Z100

faster

easier

Z100

Z100 Z100

Z100

EWC Controls Inc. 385 Highway 33 Englishtown, NJ 07726 800-446-3110 FAX 732-446-5362 E-Mail- [email protected]

Field Controls Inc. 2630 Airport Road

Kinston, NC 28504

PH: 252.522.3031

FAX: 252.522.0214

P/N 090376A0131 REV. C 10/2011

The Field Controls Steam Humidifier now comes equipped with a factory installed Z100, which acts
as a sacrificial metal. Put simply, minerals in the water will attack and cling to the Z100. The
minerals will not attack the other components inside the humidifier as long as the Z100 is present
and active.

This results in a dramatic decrease in mineral and scale build up on the critical components inside
the tank. In particular, it means less scale build up on the heating element which is subject to
damage from excessive scaling and over heating. This also means that efficiency stays high and
preventive maintenance is faster and easier.

The Z100 is positioned on the baffle plate inside the tank and is easily removed and replaced.
Remember that the Z100ʼs job is to become the target of mineral attack, so it will be heavily
covered with scale and should be replaced annually for best results.

To remove the Z100 you must have already unplugged and shutdown your steam humidifier and
allowed it to cool. The water tank has been drained, the water supply, drain lines and electrical
wiring have been disconnected and the unit has been removed from the duct.

Refer to the blow up view on Page 11. Using a phillips screwdriver, remove the two screws that
hold the baffle plate to the tank. Lift the baffle slightly back to clear the water probe and then straight
up and out of the tank. You can then see the round Z100, or rather what is left of it after a single
season. Notice the heavy scale build up on the Z100 that would have been on your element, if the
Z100 was not there. Use a rag or pliers to grasp the edges of the Z100 and simply unscrew it from
the baffle plate. Rinse off or wipe away any residual scale from the baffle plate and install a new
Z100. Leave a slight gap between the bottom of the Z100 and the baffle plate. Now re-insert the
baffle plate into the tank and secure with the two screws that were removed previously. Itʼs that
simple.

The Z100 can also benefit the older model steam humidifiers. Simply lay the Z100 down into the
baffle plate in the same location as the factory installed model. DO NOT lay the Z100 down into the
main tank. It may come in contact with the heating element and damage it. The dimensions of the
baffle plate prevent the Z100 from falling down into the tank.

SUPPLEMENT TO THE ELECTRONIC STEAM

POWER HUMIDIFIERS MODEL #S2000 AND S2020
