IN addition to the ‘Everything’ keyword indicated in chapter 4 the following specific
query functions are implemented.
Func. Description
Driver Parameter
Protocol Id.
‘1’
DART Config Query DA_Func = dart-config 49
‘2’ Dart Psswd Query DA_Func = dart-password 50
'3'
DAP Config Command DA_Func = dap-config
51
'4'
DAP Log Query
DA_Func = dap-log
52
'5'
DAP Unit-Type Query DA_Func = dap-unit
53
'6'
DAP Stat Query
DA_Func = dap-stat
54
'7'
DAP Xtra Query
DA_Func = dap-xtra
55
'8'
DAP Menu Query
DA_Func = dap-menu
56
'A'
Chiller Stat Query
DA_Func = chiller-stat
65
'B'
Chiller Xtra Query
DA_Func = chiller-xtra
66
'C'
Chiller Menu Query
DA_Func = chiller-menu
67
‘D” Dart Status DA_Func = dart-status 68
'E'
DAP80 Menu Query
DA_Func = dap80-menu
69
'G'
DAP Analog Query
DA_Func = dap80-analog
71
'H'
DAP Channels Query DA_Func = dap80_channles
72
Each of the above queries returns a complex set of data consisting of many sub-fields.
Contact Data-Aire for a complete listing of the data composite returned.
The following special / diagnostic functions are also implemented.
Driver Parameter
Protocol Id.
DA_Func = All-Listen
11
DA_Func = Ack
6
DA_Func = Dart-Transparant
2
DA_Func = Dart-Opaque
3
DA_Func = Test-Echo
16
DA_Func = Test-No-Echo
15
DA_Func = Unit-Talk
13
With the exception of the Unit-Talk command, these are nodeless commands.
When using any of these special commands no other DA_* fields need be specified.
The operation of these functions is as follows ;
All-Listen instructs the all units in the network to switch their relays to the listen position.
Those units already in the listen position will do nothing. Those in the talk position will
first echo the all-listen command and then switch their relays to the listen position. A
pause of 0.15 seconds is required after the transmission of this command, to allow the
units time to switch their mechanical relays.
6.1.2
DA_Field Parameter - Permitted values.
Legal values depend on the value of DA_Func.
