Driver Manual

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042

Visit our website: www.fieldserver.com E-mail: [email protected]

Page 12

4.4.5

Map of How Data Aire Device Data is stored in a Data Array



In the example of 4.4.1 the Fieldserver listens passively for all possible data from the device called ‘unit1’
and stores the data in an array called ‘DA_01’.


The data that is obtained from ‘unit1’ is dependent on the type of device. Irrespective of the device type
the arrangement of data, stored in DA_01, is fixed. If a data field cannot be obtained from ‘unit1’ then
the array is left with a zero value for that data field.

Table 4.4.5.1: Array Locations of ‘Everything’
In the following table the array location indicates the offset in the data array at which a data field can be
found. (This offset is relative to the offset specified in the map descriptor.) The columns headed 2,3 …
indicate the unit types for which the data fields are available. For example: The field ‘d_temp’ can be read
from unit types 2,5,6,7,9 but not from any of the other unit types. It is beyond the scope of this manual to
describe each field and to indicate valid ranges. Such information should be obtained from the Data Aire
Corporation.

‘x’ Indicates Read only
‘X’ Indicates a point that can be read & written.
‘w’ Indicates a write only point.

Array
Location Method

Num

Elements Data Field

2 3 4 5 6 7 8 9 14 15 Message Type

1

1

1

Zone

w w w w w w w w w Dap-Config

2

1

1

Inhibit

w w w w w w w w w Dap-Config

3

4

1

unitType

x x x x x x x x x x Dap-Unit

4

2

1

temp

x

x x x x

Dap-Stat

5

2

1

hum

x

x x x x

Dap-Stat

6

2

1

d_temp

x

x x x x

Dap-Stat

7

3

8

mode

x

x x x x

Dap-Stat

23

3

8

hold

x

x x x x

Dap-Stat

39

1

1

cs_on

x

x x x x

Dap-Stat

40

1

1

hs_on

x

x x x x

Dap-Stat

41

1

1

valvePCT

x

x x x x

Dap-Stat

42

1

1

hVlvPCT

x

x x x x

Dap-Stat

43

4

14

errors

x

x x x x

Dap-Stat

57

2

1

hiTemp

x

x x x x

Dap-Stat

58

2

1

loTemp

x

x x x x

Dap-Stat

59

2

1

hiHum

x

x x x x

Dap-Stat

60

2

1

loHum

x

x x x x

Dap-Stat

61

1

1

chilled_water

x

x x x x

Dap-Stat

62

1

1

compressor_config

x

x x x x

Dap-Stat
