2-21
ITEM PART # COMPONENT
Box Assembly, Transformer
A 106-1380 100-120V FMPH152/155, FMPH352/355, FMPH452/455
B 106-3818 100-120V BIPH 252/255, BIPH 452/455, FMPH252/255
C 106-4888 100-120V BIPH 352/355
D 106-3819 208-240V BIPH 252/255 and BIPH 452/455 CE/Non-CE Export
E 106-3817 250V BIPH 252 and BIPH 452 CE/Non-CE Export
F 106-3824 208-240V BIPH 352/355 CE/Non-CE Export
G 106-3823 250V BIPH 352/355 CE/Non-CE Export
1 106-3820 Cable Assembly, Transformer Box #1
2 106-3821 Cable Assembly, Transformer Box #2
3 106-1011 Cable Assembly, Transformer Box Line
4 106-1016 Cable Assembly, Transformer Box Filter Pump
5 106-3827 Cable Assembly, Transformer Box #1 (On Box G this PN# becomes 106-4898)
6 106-4990 Cable Assembly, Transformer Box Line
7 106-3825 Cable Assembly, Transformer Box #3
8 106-3826 Cable Assembly, Transformer Box Filter Pump
9 106-3316 Cable Assembly, Transformer Box Line
10 200-1415 Cover, Transformer Box
11 200-6721 Plate, Strain Relief
12 200-2318 Cover, Transformer Box Cable Plate
13 807-0012 Relay, 18 Amp 1/3-HP 24V Coil
14 807-0070 Terminal, Ground Lug
15 807-0155 Connector, 9-Pin Male
16 807-0680 Transformer, 208-240V/24VAC 50/60Hz 20VA
17 807-0800 Transformer, 100-120V/24VAC 50/60Hz 50VA ( On Box C PN# is 807-1238)
18 807-1973 Terminal, Post
19 807-1999 Transformer, 208-240V V/F Dual Voltage
20 807-2176 Transformer, 100-120V V/F Dual Voltage
21 809-0052 Nut, 10-24 Hex
22 826-1362 Nut, 1/4-20 Hex (Pkg. of 10)
23 826-1363 Screw, 8-32 X 1/2-inch Slotted Truss Head (Pkg. of 25)
24 809-0123 Screw, 10-24 X 3/4-inch Slotted Truss Head
25 826-1389 Screw, 1/4-20 X 3/4-inch Hex Head (Pkg. of 10)
26 826-1366 Nut, 4-40 Keps Hex (Pkg. of 25)
27 809-0247 Nut, 8-32 Keps Hex
28 826-1376 Nut, 10-32 Keps Hex (Pkg. of 10)
29 826-1359 Screw, 4-40 X 3/4-inch Slotted Round Head (Pkg. of 25)
30 809-0360 Screw, #8 X 3/8-inch Hex Washer Head
31 809-0656 Screw, 4-40 X 3/8-inch Slotted Round Head
32 810-1164 Block, One-Piece Screwless Terminal
33 816-0217 Insulation, Terminal Block Paper
34 824-1242 Box, Transformer BIPH252, 452
35 824-1301 Box, Transformer BIPH352, 552
36 807-1683 Relay, Hood 12V DC
37 807-0157 Connector, 6-Pin Male
38 816-0219 Paper, CE Triple Terminal Block Insulating
39 810-1163 Block, 3 Places Screwless Terminal
40 106-4894 Cable Assembly, Transformer Box Filter Pump
41 106-4893 Cable Assembly, Transformer Box Line
Continued on Next Page
