2-18
ITEM PART # COMPONENT
1 810-1164 Block, One-Piece Screwless Terminal
2 200-5996 Box, One-Piece Component
3 807-1926 Bushing, .875-inch Split
4 807-3483 Cable, 21-inch Ignition H50/H52 –For 807-3366/3365 Modules
* 826-2024 Cable, Ignition - 1 wire / 1 rajah
* 826-1721 Cable, Ignition – 2 wire / 2 rajah
5 807-3484 Connector, Rajah
6 106-0531SP Fuse Assembly, Inline
7 816-0217 Insulation, Terminal Block Paper
8 807-2971 Ignition Module, Australian
9 807-1006 Ignition Module, CE and Non-CE export (except Australia, Canada, HK, Mexico)
10 807-3366† Ignition Module, Dual-Spark Full-Vat (U.S., Canadian, HK, and Mexican units)
807-3365† Ignition Module, Single-Spark Ignition Module Dual-vat (U.S., Canadian, HK,
and Mexican units)
11 826-2264 Interface Board Kit; U.S., CE and non-CE (except Hong Kong)
106-6706 Interface Board SMT, U.S., CE and non-CE (except Hong Kong)
807-4330 Sound Device/Speaker Adapter Harness SMT
807-4343 Wire Harness, SMT Interface Board to Ignition Module
12 106-0387 Interface Board, Australian
13 806-4973 Interface Board, Hong Kong
14 807-1359 Mount, Ty-Wrap
15 826-1366 Nut, 4-40 Keps Hex (Pkg. of 25)
16 809-0250 Nut, 6-32 Keps Hex
17 807-0833 Relay, DPDT 5A 12VDC Latch (See NOTE 1.)
18 806-2071 Cable, 15-pin Computer to Interface Board
19 809-0441 Screw, #8 X 1½-inch Hex Washer Head
20 826-1359 Screw, 4-40 X ¾-inch Slotted Round Head (Pkg. of 25)
21 809-0098 Screw, 6-32 X 1¼-inch Slotted Round Head
22 826-1346 Spacer, Ignition Module (Pkg. of 10)
23 810-2763 Spacer, Interface Board
24 810-2243 Spring, Relay Retaining
25 826-1337 Tab, ¼-inch Terminal (Pkg. of 5)
26 807-1948 Ty-Wrap
27 806-6085SP Wire Assembly, Ignition Module
28 807-3843 Fuse 3A 250V Domestic
807-3293 Fuse 5A 125V International Only
* 807-1200 Ignition Wire, 27”
* 807-1878 Ignition Wire, 19”
* 807-3520 Sound Device, High Output
* Not illustrated.
† For Dual-vat units, use 807-3365 Single Spark Ignition Module (see NOTE 1).
NOTE 1: U.S., Canadian, Hong Kong, and Mexican units use two different modules depending upon the
configuration of the frypot. Dual-Vat units use two 807-3365 Single-Spark Ignition Modules. Full-Vat units
use one 807-3366 Dual-Spark Ignition Module. Also, in full-vat units, only one latch relay (Item 17) is used,
located in the lower right socket.
