5-3
ITEM PART # COMPONENT
1 807-3764 Element, 208VAC 6.3 kW Heating
2 823-3760 Element Assembly, 208 VAC 6.3 kW Heating
3 200-3435SP Element/Probe Guard, Left or Right
4 106-2120 Fuse Assembly, 5 Amp w/Leads
807-3750 Fuse, 300V 5 Amp
807-3751 Holder, Fuse
5 106-2135 Panel Assembly, Power/Reset/Boil-Out
807-3574 Switch, Power
807-3576 Switch, Reset
807-3579 Switch, Boil-Out
6 807-3611 Relay, 24VAC Coil (Boil-Out Relay)
7 807-3722 Interface Board, 208/230V (Thermatron Board)
8 106-0802 Faceplate Assembly, Solid State Thermatron Controller
816-0534 Knob, Thermatron Controller
106-0801 Potentiometer Assembly, Thermatron Controller
9 807-3610 Terminal Block
10 807-3748 Circuit Breaker, 3-Pole 240VAC
11 807-3743 Contactor, 208/240VAC 50/60Hz
12 807-3682 Transformer, 230VAC
13 807-2103 Microswitch, CE Straight Lever
14 106-2148 Probe Assembly, 1824E/2424E Temperature
15 807-3515 Thermostat, Operating
* 816-0546 Knob, Operating Thermostat
16 807-3759 Thermostat, High-Limit w/Manual Reset
* Not illustrated
