B. EQUIPMENT INSTALLATION RECORD

*Record the following details at the time of the installation and retain for future references:

A. INSPECTION-RECEIPT OF EQUIPMENT

Examine equipment at the time of receipt. Check that the power cable is not cut or damaged, and that all
equipment is correct for the installation. Handle the pump, cable and motor carefully. This is very important
because of the precise alignment of the assembly and the vulnerability of the cable. Report any damages or
shortages immediately to the freight carrier agent and make notes on the freight bill of lading. This will facilitate
a satisfactory and prompt processing of a claim adjustment.

2

PUMP DATA

________________________________________________________

Manufacturer

____________________________________________

Model Number

___________________________________________

Serial Number

____________________________________________

Date of Installation

________________________________________

PUMP SETTINGS

____________________________________________________

Well Casing Inside Diameter

_________________

in.

Well Depth

_________________

ft.

Size of Drop Pipe(Riser)

_________________

in.

length

_________________

ft.

Standing Water Level

_________________

ft. below ground

Depth to Lowest Perforation

_________________

ft.below ground

Number of Check Valves

_________________

Power Cable Size

_________________

in.

length

_________________

ft.

Length of Air Line

_________________

ft.

MOTOR DATA

______________________________________________________

Maunfacturer

____________________________________________

Horsepower

______________________________________________

Voltage/Phase/Cycle

________/_________/_____________________

Full Load Amperage

______________________________________

Motor Size

______________________________________________

Model

__________________________________________________

Serial Number-Date Code

__________-________________________

Pump Capacity and Head

___________________________________

Installed by

______________________________________________

Address

_________________________________________________

Phone No

_______________________________________________
