Colour monitor B15-1
A26361-K905-Z100-2-5E19 English - 13
The first function ( H-Position ) is highlighted.
Ê If necessary, press the 6 or 5 button to
mark the desired icon.
Ê Press the SELECT/MENU button to select
the highlighted function.
Ê Press the 6 or 5 button to adjust the
value for the selected function.
Ê Press the EXIT/AUTO button to exit the
function.
Ê If necessary, press the button 6 or 5 to
mark another function or press the
EXIT/AUTO button to return to the main
menu.
All changes are stored automatically.
If you want to change other settings, select the corresponding function from the OSD main menu. All
possible adjustments of the main menu are described in the following.
Adjusting the brightness and contrast
Calling the Brightness / Contrast setting window.
Brightness Setting the brightness of the display
With this function you change the brightness of the background lighting.
Contrast Setting the contrast of the display
With this function you modify the contrast of bright colour tones.
Auto Level Setting the brightness of the display
With this function you can automatically set the contrast. Press the
SELECT/MENU button to activate the function.
i
If the contrast is set too high, bright surfaces can no longer be distinguished from very
bright surfaces. If the contrast is set too low, the maximum brightness will not be
achieved.
Adjusting size and position
Calling the Image adjust setting window
H-Position Adjusting the horizontal position
With this function you move the picture to the left or to the right.
