24
ok
4. Search the device path to the secondary LAN port with a show-nets command from ok prompt of a
client system.
ok show-nets
Example
ok show-nets
a) /pci@83,2000/FJSV,pwga@1
b) /pci@1f,4000/FJSV,pgsb@4
q) NO SELECTION
Enter Selection, q to quit:
5. From ok prompt of a client system, please start a client system using the secondary LAN port.
ok boot /pci@83,2000/FJSV,pwga@1
6. Install the Solaris
4.3.2.6 Configuring VLAN interface
4.3.2.6.1 IEEE 802.1Q TagVLAN
The outline about a VLAN interface and directions required in order to setup VLAN interface are explained.
About IEEE802.1Q TagVLAN
By using VLAN, traffic management of two or more networks by a single physical interface becomes
possible. In order to create a VLAN environment, which resembles Figure 4.1 Example of VLAN
environment, a VLAN setup (VLAN ID and Tagged/Untagged) of a switch is required.
