8
L i f e B o o k i S e r i e s B I O S
Primary Slave Submenu of the Main Menu
The Primary Slave submenu is for the internal CD-ROM
drive. The drive type is displayed on this menu as well as
the Main menu. Your notebook auto-senses the charac-
teristics of the internal CD-ROM Drive installed. Note that, although Auto is the default setting for this
submenu, the Hard Disk setting is illustrated, since it
contains all of the menu fields.
The actual hard drive label shown may vary.
Figure 3. Primary Slave Submenu
Table 3: Fields, Options and Defaults for the Primary Slave Submenu of the Main Menu
Menu Field Options Default Description
Type: ■ Auto
■ None
■ CD-ROM
■ Hard Disk
[Auto] Selects the ATA/ATAPI device type. Select Auto to have the type
automatically identified by the BIOS at POST. If None is selected, all
of the following Set-up items do not appear. Select CD-ROM or
Hard Disk for appropriate drive type installed at this connection.
Cylinders: ■ A number
between 0
and 65,535
–— This item appears only when Hard Disk is selected. When Hard Disk
is selected, you can change the value. This field is changed by
incrementing (pressing the [Spacebar]) or by typing in the number.
Heads: ■ A number
between 1
and 16
–— This item appears only when Hard Disk is selected. When Hard Disk
is selected, you can change the value. This field is changed by
incrementing (pressing the [Spacebar]) or by typing in the number.
Sectors: ■ A number
between 0
and 63
–— This item appears only when Hard Disk is selected. When Hard Disk
is selected, you can change the value. This field is changed by
incrementing (pressing the [Spacebar]) or by typing in the number.
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
Main
Item Specific Help
Select ATA/ATAPI drive
installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
Except [Auto]
You enter parameters of
the drive.
[None]
The drive is disabled.
Primary Slave [TOSHIBA DVD-ROM SD-C2402-(PS)]
Type: [ Auto ]
Multi-Sector Transfers: [Disabled]
LBA Mode Control: [Disabled]
PIO Transfer Mode: [Fast PIO 4]
DMA Transfer Mode: [Ultra DMA 2]
▲
