7
Maximum
Capacity: ■ Display only –— Displays the maximum capacity of the drive calculated from the
parameters of the hard disk when Hard Disk is selected.
Multi-Sector
Transfers: ■ Disabled
■ 2 Sectors
■ 4 Sectors
■ 8 Sectors
■ 16 Sectors
■ 32 Sectors
■ 64 Sectors
■ 128 Sectors
[16 Sectors] This option cannot be changed when Auto is selected. Specify the
number of sectors per block for multiple sector transfer. MAX refers
to the size the disk returns when required.
LBA Mode
Control: ■ Disabled
■ Enabled
[Enabled] Enables or disables logical Block Addressing in place of Cylinder,
Head, Sector addressing. This option cannot be changed when
Auto is selected.
PIO Transfer
Mode: ■ Standard
■ Fast PIO 1
■ Fast PIO 2
■ Fast PIO 3
■ Fast PIO 4
[Fast PI0 4] Selects the method for moving data to/from the drive. Autotype
the drive to select the optimum transfer mode. This option cannot
be changed when Auto is selected. Multi-word DMA is
automatically set to mode 1 for Fast PIO 1, Fast PIO 2, Fast PIO 3,
and set to mode 2 for Fast PIO 4 / DMA.
DMA Transfer
Mode: ■ Disabled
■ Multiword
DMA 1
■ Multiword
DMA 2
■ Ultra DMA 0
■ Ultra DMA 1
■ Ultra DMA 2
[Ultra DMA 2] Selects the method for moving data to/from the drive. Autotype
the drive to select the optimum transfer mode. This option cannot
be changed when Auto is selected.
Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu
Menu Field Options Default Description
