FS453/4 AND FS455/6

DATA SHEET: HARDWARE REFERENCE

8.2 88-Lead FBGA Package

Figure 10 FBGA Package Outline & Dimensions

JANUARY, 2005, VERSION 3.0

29

COPYRIGHT

©2003-4 FOCUS ENHANCEMENTS, INC.

FOCUS Enhancements Semiconductor

This manual is related to the following products:

FS455 FS456 FS454
