FS453/4 AND FS455/6 DATA SHEET: HARDWARE REFERENCE
JANUARY, 2005, VERSION 3.0 18 COPYRIGHT ©2003-4 FOCUS ENHANCEMENTS, INC.
FOCUS Enhancements Semiconductor
Pin
Name
FBGA
Pin
Number
PQFP
Pin
Number
Type/Value Pin Function Description
BLANK M11 38 GTL/TTL input Digital BLANK VGA input. True outside of
GCC active area. Connects to GCC blank pin
(or to ground if a GCC blank pin is not
available).
FIELD N10 37 GTL/TTL
output Digital FIELD output. Delay and polarity
programmable.
