Chapter 5 location of parts, 1 antenna unit, Danger – Furuno FR-8111 User Manual
Page 59
5 - 1
Figure 5-1 Antenna unit (all models), cover opened
Antenna motor
24 rpm: D8G-516
36 rpm: D8G-570
BEARING SIGNAL
GENERATOR Board
MP-3795
Reed switch
N photo No. 639
Chapter 5
LOCATION OF PARTS
5.1 Antenna Unit
This equipment uses high
voltage electricity which
can shock, burn or cause
death.
Only qualified personnel
should work inside the
enclosures.
DANGER
