FPX 32 DVS Artisan Face
Charcoal: 98500507 Patina Bronze: 95300398
Page 2 of 3 17601079 - 9/14/11 © Travis Industries, Inc.
Bracket Installation
Install the face mounting brackets to
the heater with the included nuts.
NOTE
: The brackets
install with this pair of
closely spaced
flanges at the top.
Face Installation
Attach the face using the four
bolts included with the face.
Make sure the door does
not open while installing.
Adjustable
Wrench
