Model D2424LVmkII Quick Operation Guide
17
Everybody makes mistakes. If you make a mistake in recording, you can restore and re-do the data that existed
before the mistake occurred. These functions are called
“Undo” and “Redo ,” and are executed by the [UNDO/REDO]
key on the control panel.
The Undo function enables you to cancel the latest recording or edit and restore the previous state. Using the Redo
function after using the Undo function enables you to cancel the Uno operation and restore the latest recording or
edit. These functions have some limitations as described in the
below.
As described earlier in "Formatting a new disk" , if you format the disk with the multiple undo function ON,
"multiple undo" is possible. See "Multiple undo function" in the Reference manual.
You can repeatedly use the Undo/Redo functions until you
perform one of the following operations:
• You make a new recording.
• You perform a new edit (Copy/Paste, Move/Paste, Auto
Punch in/out, Erase, etc.).
• You turn off the power to the recorder.
• You select a different Program.
• You execute the Multiple Undo operation.
1. After making a recording (or playing back a newly
recorded data), press the [UNDO/REDO] key.
The recorder displays “ Undo! ”, then “ COMPLETED ! ”,
and displays the previous Time Base indication.
Undoing the recording will restore the status obtained
before recording.
Before recording
After recording
1, 2
([UNDO/REDO] key)
Performing the Redo operation will cancel the Undo
operation and restore the state obtained after recording.
The single undo/redo function executes undo/
redo operation only against the latest take.
The "multiple undo function" can execute undo
against all takes after the current disk had been
formatted. When the multiple undo function is
set to ON, the recorder stores all takes automati-
cally and can recall the desired take (undo) if
necessary.
Undo and redo recording (single undo/redo)
• Multiple undo is possible only when the current
disk is formatted with the "Multiple undo
function" ON.
• A disk formatted with the multiple undo function
ON has more information stored on it more than
a disk formatted with the multiple undo function
OFF.
• With the single undo/redo function described
above, the data you undo will be erased when the
next recording is done. Therefore, once you
execute a single undo, the undone take cannot be
restored even if you execute multiple undo later.
* Refer to the Reference manual for details.
2. To cancel the undo operation, press the
[UNDO/REDO] key again.
The recorder displays “ Redo! ”, then “ COMPLETED ! ”,
and displays the previous Time Base indication.
Recorded area
Undo Redo
∞ 42
OL
0
30
24 18
12
9 6
3
kHz
24
FS
BIT 24
∞ 42
OL
0
30
24 18
12
9 6
3
COMPLETED!
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
CLOCK
INT
∞ 42
OL
0
30 24
18
12 9
6 3
kHz
24
FS
BIT 24
∞ 42
OL
0
30 24
18
12 9
6 3
COMPLETED!
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
CLOCK
INT
HOLD
RECORD STOP PLAY REW F FWD
ALL READY
LOCATE REC END
VARI PITCH PUNCH LOCATE REHEARSAL
TAKE
RECALL STORE
EXIT/NO EXECUTE/YES PGM SEL
NEXT PREV UNDO/REDO
PREVIEW
EDIT SETUP
AUTO RTN
OUT IN AUTO PLAY START OUT IN END
LOCATE ABS 0
CLIPBOARD PLAY
AUTO
SHIFT
DISP SEL
CHARACTER
TIME BASE SEL
P.EDIT
EJECT CHASE
TC READY TC GEN M.UNDO PREV TC NEXT TC
CLIPBOARD AUTO PUNCH
AUTO RTN
LOCATE MEMORY
