8-8
8.3.1.1 Euro-Look Drain Tube Section and Associated Parts (cont.)
ITEM
EURO-LOOK
PART# ** COMPONENT
1 Drain Tube, Left/Right End Short
823-4625 Full-Vat 3”
823-4624 Dual-Vat 3”
2 Drain Tube, Left/Right Open Short
823-4643 Full-Vat 3”
823-4642 Dual-Vat 3”
3 Drain Tube, Right End Long
823-4639 Full-Vat 3”
823-4638 Dual-Vat 3”
4 Drain Tube, Left/Right Open Long
823-4641 Full-Vat 3”
823-4640 Dual-Vat 3”
5 823-4892 Drain Outlet Center Dump
6 816-0625 Sleeve 3”
7 809-0969 Clamp, 3” T-Bolt
8 810-2492 Fitting, Quick-Connect Straight (receives Teflon vent tube)
* KIT6033 Kit, Round Drain Clamp (2 or Item 7 and 1 of Item 6)
* 811-1071 Tube, Teflon Vent ¼-inch OD
* Not illustrated.
** See page 8-6 for a standard parts list.
