Fluke 943-227-15 - Manual (Page 36)

Appendix
Cable Termination Instructions
D
D-3
HV CONNECTOR NOTES (HV)
The mating HV connector, P/N 30-92-1 (Kings 1705-14), may now be terminated per the applicable Kings
data sheet attached
LOCATION
P/N DOCUMENT DESCRIPTION
SHV
92-9105-A CP-400, Kings High Voltage Connector,
SHV (1705-1) Cabling SHV, male crimp contact
Procedure, Trim Code pin (Use Tool KTH-100 with
441, 442 KTH-2062)
SHV Alternate AMP Instruction High Voltage Connector,
Connector Sheet SHV, male crimp contact
92-9105-A 408-2187 pin (Use Tool 69710-1 with
(51426-5) 220028-2 Die or Integral
Die Tool 220022-2)
SHV 32-92-1 CP-1001, Kings Cabling High Voltage Connector, SHV,
(1705-14) Procedure, CP-1000, Female solder contact pin
