FS-2 and FS-2E Studio DTE Disk Recorders User Guide
4 - 3
Part Number: MANL-0927-03
Reference
FS-2/2E LCD Display Modes
The table below shows LCD characteristics when
used with different FS-2/2E control, record, play
and stop modes:
PLAY/REC MODE FS-2/2E LCD
Stop STOP
Pause ll PLAY
Play > PLAY
Rec (Pause) ll REC
Normal Rec (Rec) REC
Retro Disk (Stop) L STOP
Retro Disk (Standby) L REC
Retro Cache (Stop) C STOP
Retro Cache (Standby) C REC
Loop Record (Stop) O STOP
Loop Record (Standby) O REC
Loop Record (Rec) O REC
Snap (Stop) STOP
Snap (Standby) ll SNAP
Snap (Rec) ll SNAP
Time Lapse (Stop) STOP
Time Lapse (Pause) ll T REC
Time Lapse (Rec) T REC
CONTROLTYPE FS-2/2E LCD
AV/C* (Stop) A STOP
AV/C* (Rec Pause) ll A REC
AV/C* (Rec) A REC
AV/C* (Play Pause) ll A PLAY
AV/C* (Play) A ALL
Syncro Slave (Pause) ll Y REC
Syncro Slave (Rec) Y REC
* AV/C is only for use when the FS-2/2E is
connected to a computer system. To control the FS-
2/2E from a camcorder, use Syncro Slave mode.
Supported RS422 Commands
Shuttle FWD 21, 13, Shuttle Speed
Shuttle Rev 21, 23, Shuttle Speed
Jog FWD 21, 11, Jog Speed
Jog Rev 21, 21, Jog Speed
Stop 20, 00
Play 20, 01
Pause 21, 13, 0
Record 20, 02
Goto Timecode 24, 31, timecode
Shuttle Speed Parameters
Pause - 0
Play Slow 6 - 1 to 100
Play Slow 5 - 101 to 200
Play Slow 4 - 201 to 300
Play Slow 3 - 301 to 400
Play Slow 2 - 401 to 500
Play Slow 1 - 501 to 999
Play Normal - 1000 to 1999
Play Fast 1 - 2000 to 2999
Play Fast 2 - 3000 to 3999
Play Fast 3 - 4000 to 4999
Play Fast 4 - 5000 to 5999
Play Fast 5 - 6000 to 6999
Play Fast 6 - 7000 to 7999
Play Fastest - 8000 to 8999
Jog Speed Parameters
Pause - 0
Step 1 Frame - 1 to 200
Play Slow 4 - 201 to 300
Play Slow 3 - 301 to 400
Play Slow 2 - 401 to 500
Play Slow 1 - 501 to 800
Play Normal - 1000 to 8999
