FS-2 and FS-2E Studio DTE Disk Recorders User Guide
1 - 7
Part Number: MANL-0927-03
INTRODUCTION
12 Pb Input : For connecting the Pb signal from component input sources.
Pb Output: For output of the Pb signal to component devices.
13 Pr Input: For connecting the Pr signal from component input sources.
Pr Output: For output of the Pr signal to component devices
14 Sync Input: For connecting the Sync signal on non sync on green component sources.
Sync Output: For connecting the Sync signal to non sync on green component devices.
15 Timecode Input: For connecting external analog VITC timecode sources.
Timecode Output: For connection to external analog VITC timecode devices.
16 Reference Video: For reference video loop through.
To use this Reference Video input, select REF VIDEO from REF VIDEO in the SETUP menu. If the loop-through jack
is not connected, make sure the output is terminated using an external 75 ohm terminator.
17 AES/EBU Digital Audio Input and Output: For connecting AES/EBU input sources or output to AES/EBU devices .
18 Stereo Audio Monitor Output: For connection of audio monitors.
19 Balanced Analog Audio Input Channels 1 and 2: For connecting balanced analog audio input sources.
Balanced Analog Audio Output Channels 1 and 2: For output to balanced analog audio devices.
20 AC In: Use the power cord supplied to connect to the power outlet. The power module contains a protective fuse.
Refer to “Replacing the Power Module Fuse” on page 1-10 for more information.
