Assembled Parts
Both Shown Actual Size
Note: Tighten and loosen all screws with a Phillips
screwdriver. Do not over-tighten.
• Fit the front brace onto one of the frames.
Hint: The front brace will only fit on the frame one way. If it does
not seem to fit, turn it around and try again!
• Insert two M3,5 x 15mm screws into the holes in the frame
and tighten.
This package contains small parts in an
unassembled state. Adult assembly is required.
Take extra care during unpacking and assembly.
CAUTION
1
Seat
Back Brace
Front Brace
Support Bar
tray
2 Frames
Front Brace
Frame
M3,5 x 15mm Screw - 8
M4,5 x 18mm
Washer Head Screw - 4
BACK VIEW
• Turn the seat face down. Insert two M3,5 x 15mm screws into the
seat and tighten.
1
