background image

System configurator and order-information guide

Start PRIMERGY RX220

PRIMERGY RX220 Status 2005-12-20

Section

I

Basic unit

System unit consisting of:

* 1U Housing including standard power supply

* Fans

- Fans for Power Supply and Chassis

* Drives / Bays

- 2 bays 1" for SATA hot-plug or "easy change" HD

- 1 bay (for accessible drives) with

- 1 IDE-CD- or DVD- or CD-RW-ROM 0,5" height

Systemboard with:

- Dual Processor Board with Opteron 940 pin socket (s. section II)

- 8 memory slots (s. section III)

- SATA RAID controller on-board (s. section IX)

- Dual LAN on-board 10/100/1000TX (s. section X)

- Graphics controller (s. section IV)

- 2 PCI Slots:

1x PCI-X 64 Bit / 133 MHz standard long

1x PCI-Express x8 standard short 1xx mm

- BMC (Baseboard Management Controller) Servermanagement Chip on board

External Interfaces:

- 1x RS-232-C (serial, 9 pins) (usable for BMC or OS or shared)

- 1x keyboard (PS/2)

- 1x mouse (PS/2)

- 1x VGA (15 pins)

- 4x USB 2.0 (2x front and 2x rear)

- 2x LAN RJ45

Cables:

1. IDE cable for CD/DVD.

2. SATA cables for up to 2 internal HDDs

3. Power cable

Software:

- ServerStart packet incl. ServerBooks CD, ServerSupport CD and ServerView

- Documentation engl. (multilingual on CD)

Mounting kit for PRIMERGY RX220 is part of the basic unit

- 1 pair of telescopic rails (650 - 790mm)

- 1 bracket DC-PC-Rack

Mounting kit for mounting of servers in in FSC 19" PRIMECENTER- racks

and all server racks conforming to EIA standard EIA-310-D for 19" racks.

Therefore the mounting kit is variable in depth from 650 - 790mm

Cables included in basic unit

Connections

Cable

PRIMERGY RX220

1. IDE CD/DVD

¡

¡

2. SATA cables HDDs

¥

¥

3. Power cable

A

Fujitsu Siemens Computers

Enterprise Products PRIMERGY Server

6 of 15
