1-20 SPARC Enterprise M8000/M9000 Servers Overview Guide • December 2010
Operator Panel Switches
The switches on the operator panel include the mode switch for setting the operation
mode and the POWER switch for turning on and off the server. To switch between
system operation mode and maintenance mode, insert the dedicated key of the high-
end server and change the mode switch setting.
TABLE 1-5 lists functions of the switches on the operator panel.
TABLE 1-5 Operator Panel Switches
Switch Name Function
POWER switch Controls the main unit power.
MODE switch Selects between maintenance and normal operation. Use the
dedicated key managed by the customer to switch between
normal and maintenance modes.
Locked This mode is set for normal operation.
Service This mode is set for maintenance.
