7. CUSTOMIZING YOUR UNIT
7-16
Contents of chart details menu (Navionics GOLD) (con’t from previous page)
Item Description Settings
Marine Features Turn marine features on or off. On, Off
Land Features Turn land features on or off. On, Off
CONTOUR LINE Soft key
Spot Soundings
Turn water depth display on or off. On, Off
Safety Contour Paint areas in dark blue (default
color) which are shallower than
depth value set. 2m (or equivalent ft, fa or PB)
5 m (or equivalent ft, fa or PB)
10 m (or equivalent ft, fa or PB)
20 m or equivalent ft, fa or PB)
Depth Contour Display depth contours. ALL: Display all depth contours
5 m: Display only 5 m* depth
contours
10 m: Display only 10 m* depth
contours.
20 m: Display only 20 m* depth
contours
OFF: Turn off depth contours.
* Or equivalent ft, fa or PB.
7.4.3 C-MAP chart attributes
Displaying the CHART DETAILS menu
C-MAP chart attributes may be turned on or off from the CHART DETAILS menu:
1. Press the MENU key.
2. Press the CHART SETUP and CHART DETAILS soft keys.
Page 2 Page 1
CHART
DETAILS
EDIT
DEPTH
INFO
RETURN
CHART
DETAILS
EDIT
DEPTH
INFO
PREV.
PAGE
SEABED TYPE
PLOTTER/OVERLAY
PORTS & SERVICE
PLOTTER/OVERLAY
UNDERWATER OBJECTS
PLOTTER/OVERLAY
RIVERS & LAKES
PLOTTER/OVERLAY
NATURAL FEATURES
PLOTTER/OVERLAY
CULTURAL FEATURE
PLOTTER/OVERLAY
LANDMARK
PLOTTER/OVERLAY
LAT/LON GRID
PLOTTER/OVERLAY
CHART BOUNDARIES
AUTO PLOTTER/OVERLAY
MIXING
OFF
CHART LEVEL
UNLOCK
NEXT
PAGE
DE-CLUTTER
ON
CHART DISPLAY MODE
FULL
SAFETY STATUS
PLOTTER/OVERLAY
WAYPOINT
PLOTTER/OVERLAY
WAYPOINT NAME
PLOTTER/OVERLAY
NAMES
PLOTTER/OVERLAY
BUOYS NAME
PLOTTER/OVERLAY
NAV-AIDS
US
LIGHT SECTORS
FLASHING PLOTTER/OVERLAY
ATTENTION AREAS
PLOTTER/OVERLAY
TIDES CURRENTS
PLOTTER/OVERLAY
PERSPECTIVE
ON
Chart details menu (C-MAP)
