CASEMENT CHASSIS "SC" SERIES PARTS LIST

REF

DESCRIPTION

PART NO#

CASEMENT

CODE

CHASSIS SYSTEM PARTS

SC06L10

GROMMET, COMPRESSOR

01150931

3

790

NUT, COMPRESSOR

91002300

3

999

WASHER, COMPRESSOR MT.

01423005

3

999

CLIP, THERMOSTAT

61715100

1

764

SHELL ASSEMBLY

61498301

1

770

ANGLE, SHELL TOP SUPPORT

61427001

1

999

SILL PLATE

61074800

1

999

ANGLE, WINGBOARD ASSEMBLY (L\S)

61427200

1

999

ANGLE, WINGBOARD ASSEMBLY (R\S)

61427201

1

999

ANGLE ASSEMBLY - LEFT SIDE STUD

61427101

1

999

ANGLE ASSEMBLY - RIGHT SIDE STUD

61427103

1

999

GASKET, ANGLE TOP SHELL SUPPORT

60467399

1

780

GASKET, WINGBOARDS

60467377

2

780

BRACKETS, SUPPORT

61109503

2

999

*

SCRIPT, FRIEDRICH

60169103

1

999

*

NUT, FRIEDRICH SCRIPT

91002900

2

999

GASKET, CHASSIS

60073301

1

780

FRONT, DECORATIVE

61077501

1

750

*

HARDWARE KIT

60714305

1

999

SHIPPING CARTON

61841905

1

999

PAD, SHIPPING TOP

61630802

1

999

PAD, SHIPPING TOP

61632000

1

999

PAD, SHIPPING VERTICAL

61631900

1

999

PAD, SHIPPING VERTICAL

61631901

1

999

OPTIONAL ACCESSORIES

KIT, INSTALLATION (DOUBLE HUNG WINDOW)

01900241

1

ANTI-ICE KIT

60553104

1

START KIT

61003803

1
