29
* PARTS NOT SHOWN
CASEMENT CHASSIS "SC" SERIES PARTS LIST
REF DESCRIPTION PART NO# CASEMENT CODE
ELECTRICAL PARTS
SC06L10
THERMOSTAT 61350305 1 120
OVERLOAD 60364583 1 190
CAPACITOR 61380378 1 150
SUPPLY CORD 60500171 1 220
SWITCH 60895102 1 130
FAN MOTOR 60571468 1 110
REFRIGERATION SYSTEM PARTS
COMPRESSOR 61441027 1 600
EVAPORATOR COIL 61600204 1 400
CONDENSER COIL 61600347 1 410
CAPILLARY TUBE ASSY 61697300 1 471
FILTER DRIER (LIQUID) 61481300 1 480
CHASSIS SYSTEM PARTS
SHROUD, CONDENSER 61076204 1 720
FAN BLADE, COND. 60063411 1 710
BLOWER WHEEL, EVAP. 60415201 1 700
RING, ORIFICE 60232200 1 738
WRAPPER, BLOWER 61107600 1 741
FRONT, BLOWER 61076501 1 742
HOUSING, BLOWER 61076801 1 740
DECK 61077702 1 745
PANEL ASSEMBLY, L\S 61077301 1 747
SCREEN, BLOWER GUARD 61109001 1 774
BRACKET, CONTROL MOUNTING 61075902 1 999
PANEL, CONTROL (DECORATIVE) 60416203 1 760
KNOB, CONTROL 61493903 2 761
COVER, BULKHEAD ASSLY. 61076302 1 746
BRACE, COND.SHROUD 61075502 1 722
COVER, CAPACITOR 61074904 1 999
MOUNT, MOTOR 61645402 1 900
CLIP, MOTOR MOUNT 01060445 2 999
COVER, CONDENSER SHROUD 61076101 1 721
BASE PAN ASSLY. 61498705 1 730
DRAIN PAN 60199801 1 840
TUBE, DRAIN 60203200 1 800
GUARD, SPLASH 61440300 1 999
FILTER, AIR 60483801 1 754
