Please Note: If the axle/linkage assembly has detached
from the vehicle body during shipment, please fit it back
onto the fork on the front of the vehicle body. Make
sure the center axle is toward the rear of the vehicle
(see inset).
• Turn the vehicle body upside down.
• Fit a washer onto one end of the front axle.
• Slide the front wheel, bushing side first, onto the
front axle.
• Turn the front wheels over.
• Fit a wheel bushing into the rectangular opening in each
front wheel.
2
• Apply label #2 to the recessed circle on each front wheel.
Wheel
Bushing
2
• Slide a round bushing onto the front axle and press it
into the center of the front wheel.
• Fit a cap nut onto the end of the front axle.
• Tap the cap nut with a hammer to secure it on the
front axle.
• Repeat assembly steps 3 and 4 to assemble the other
front wheel to the other side of the vehicle body.
• Position the vehicle body upright.
Inset
Front Wheel
Vehicle Body
Front Axle
Cap Nut
4
1
Assembly
F
Front Wheel
Front Wheel
9
Front Wheel
Round
Bushing
Washer
3
Steering
Column
Wheel
Bushing
