Page 18
Power supply cord requirements for U.S.A
Only a UL listed power-supply cord kit at least 6ft (1.8m) long and rated 120/240 V min, 30 A and
marked with use for clothes dryers shall be used.
This shall have ring terminals to connect to the dryer.
The UL-rated strain relief included with it shall be suitable for a 1
1
/
8
” (28.5mm) hole.
If your outlet looks like this
Choose this power supply cord
Connecting by direct wire
Power supply cable must match power supply (4-wire or 3-wire) and be:
Flexible armoured or non-metallic sheathed copper cable (with ground wire). All current-carrying
wires must be insulated.
10 gauge AWG solid copper wire (do not use aluminium wire).
At least 6 feet (182 cm) long.
A UL approved strain relief must be used.
4 wire
� ����
