69
S p e c i f i c a t i o n s
Specifications
This section provides the hardware and environmental
specifications for your Fujitsu LifeBook notebook.
Specifications of particular configurations will vary.
CONFIGURATION LABEL
There is a configuration label located on the bottom of
your LifeBook notebook. (See Figure 2-7 on page 10 for
location). This label contains specific information
regarding the options you’ve chosen for your notebook.
Following is an example label and information on how to
read your own configuration label.
Figure 7-1 Configuration Label
MICROPROCESSOR
AMD Turion™ 64 X2 Mobile Technology micropro-
cessor (To determine the processor speed, right-click My
Computer, select Properties, then select the General tab.)
CHIPSET
ATI Radeon® Xpress 1150
MEMORY
System Memory
■ DDR2 667 MHz SDRAM dual-channel memory
module.
■ Two DIMM slots; upgradeable to 4 GB of total
memory (2 GB x 2). Note: If 4 GB are installed, only
3.25 GB are usable by the system due to operating
system constraints.
Cache Memory
Depending upon the system processor, cache memory is
either 2 MB or 4 MB cache on-die
VIDEO
Built-in color flat-panel TFT active matrix LCD display
with simultaneous display capability
Video Color and Resolution
15.4" Crystal View WXGA:
■ Internal: 1280 x 800 pixel resolution, 16M colors
■ External: 1600 x 1200 pixel resolution, 16M colors
■ Simultaneous Video: Max. 1280 x 800 pixel resolution,
16M colors
Video RAM
Up to 256 MB (selectable in the BIOS from 32 MB to 256
MB) of shared memory using Unified Memory Architec-
ture (UMA). The amount of selectable Video RAM is
dependent upon the amount of main memory installed,
as noted in the following table.
Table 7-1 Video RAM
AUDIO
■ Realtek codec ALC262
■ Headphones: Stereo headphone/line-out jack, 3.5
mm, 1 V
rms
or less, minimum impedance 32 Ohms
■ Microphone: Stereo microphone/line-in jack, 3.5 mm,
100 mV
rms
or less, minimum impedance 1.5K Ohms
■ Two built-in stereo speakers, 20 mm diameter
MASS STORAGE DEVICE OPTIONS
■ Hard Drive: 120 GB, P-ATA, 4200 rpm, Ultra-DMA
100, 2.5”, 9.5 mm, protected by smart Shock Sensor
technology on main PCB
■ Dual-Layer Multi-Format DVD Writer: modular 8x
DVD-R (4x Dual-layer DVD-R), 6x DVD-RW, 8x
DVD+R (4x Dual-layer DVD+R), 8x DVD+RW, 5x
DVD-RAM, 8x DVD-ROM, 24x CD-R, 10xW/16xR
CD-RW, 24x CD-ROM
FEATURES
Integrated Pointing Device
■ Touchpad pointing device with fingerprint sensor that
can also be used for scroll function.
■ Optional Point and Write Pad with active stylus input
Communications
Modem: Internal V.90 standard 56K fax/modem
(ITU V.90, 56K data, 14.4K fax)
AX3XXXXXXXXXXXXX
A3120, AMD Turion X2, VHP, DL DVD, 1GB, 120G, WLAN, 15.4WXGA
FPC P/N: FPCMXXXXX
Configuration P/N:
Operating
Hard Drive
Configuration ID Part Number
Processor Model # Screen Size/Type
Memory
System
Communications
Media Drive
Main
Memory
256 MB 512 MB 768 MB 1 GB +
Default
VRAM
32 MB 64 MB 64 MB 64 MB
Maximum
VRAM
64 MB 128 MB 128 MB 256 MB
