STATUS LED
Identify a suitable mounting location for the status LED.
Make sure that there is at least 3/4” clearance behind
the selected mounting location.
1
Drill a 9/32” mounting hole.
If necessary, remove the selected trim panel
2
3 4
Insert status LED into drilled hole.
5
If necessary, reinstall any interior trim panels removed
during this procedure.
6
The LED will plug into the main wiring harness during
the wiring steps. Make sure to leave the LED pigtail
accessible.
