2-1
McDonald’s SinBaD SINGLE BASKET DISPENSER
CHAPTER 2: INSTALLATION AND OPERATION
FINDING YOUR WAY AROUND YOUR
NEW
SinBaD
UNIT
RUN Switch
Lid
Basket Rack
Basket Rack
Receiver Bracket
Basket Rack
Crumb Pan
ON/OFF
Rocker Switch
Hopper Locking Rim
Sight Glass
Hopper
Rating Plate
Control Panel
Dispensing Chute
(rests on Load
Cell Arms)
Basket Locator Rack
w/Crumb Pan Below
SinBaD
SinBaD
0.5
LB
1.0
LB
1.5
LB
PROGRAM Switch
CHECK HOPPER Indicator
CLEAN Switch
BATCH WEIGHT Selectors
